- UIScrollView *horizontalScrollView = [[UIScrollView alloc] init];
- horizontalScrollView.backgroundColor = [UIColor orangeColor];
- horizontalScrollView.pagingEnabled =YES;
- // 添加scrollView添加到父视图,并设置其约束
- [self.view addSubview:horizontalScrollView];
- [horizontalScrollView mas_makeConstraints:^(MASConstraintMaker *make) {
- make.top.and.left.mas_equalTo(10);
- make.right.mas_equalTo(-10);
- make.height.mas_equalTo(100);
- }];
- // 创建过渡视图并设置contentSize和其约束
- UIView *horizontalContainerView = [[UIView alloc] init];
- [horizontalScrollView addSubview:horizontalContainerView];
- [horizontalContainerView mas_makeConstraints:^(MASConstraintMaker *make) {
- make.edges.equalTo(horizontalScrollView);
- make.height.equalTo(horizontalScrollView);#//水平滚动高度固定,这个很重要
- }];
- //过渡视图上添加子视图
- UIView *previousView =nil;
- for (int i =0; i <10; i++) {
- UILabel *label = [[UILabelalloc]init];
- label.textAlignment =NSTextAlignmentCenter;
- label.backgroundColor = [UIColorcolorWithHue:(arc4random() %256 / 256.0)
- saturation:(arc4random() %128 /256.0) +0.5
- brightness:(arc4random() %128 /256.0) +0.5
- alpha:1];
- label.text = [NSStringstringWithFormat:@"第 %d个视图", i];
-
- //添加到过渡视图,并设置子视图的约束
- [horizontalContainerView addSubview:label];
- [label mas_makeConstraints:^(MASConstraintMaker *make) {
- make.top.and.bottom.equalTo(horizontalContainerView);
- make.width.equalTo(horizontalScrollView);
-
- if (previousView) {
- make.left.mas_equalTo(previousView.mas_right);
- }
- else {
- make.left.mas_equalTo(0);
- }
- }];
-
- previousView = label;
- }
- #// 设置过渡视图的右距(此设置将影响到scrollView的contentSize)这个也是关键的一步
- [horizontalContainerView mas_makeConstraints:^(MASConstraintMaker *make) {
- make.right.mas_equalTo(previousView.mas_right);
- }];
- UIScrollView *verticalScrollView = [[UIScrollView alloc] init];
- verticalScrollView.backgroundColor = [UIColor greenColor];
- verticalScrollView.pagingEnabled =YES;
- // 添加scrollView添加到父视图,并设置其约束
- [self.view addSubview:verticalScrollView];
- [verticalScrollView mas_makeConstraints:^(MASConstraintMaker *make) {
- make.left.mas_equalTo(10);
- make.bottom.and.right.mas_equalTo(-10.0);
- make.height.mas_equalTo(100);
- }];
- // 设置scrollView的子视图,即过渡视图contentSize,并设置其约束
- UIView *verticalContainerView = [[UIView alloc] init];
- [verticalScrollView addSubview:verticalContainerView];
- [verticalContainerView mas_makeConstraints:^(MASConstraintMaker *make) {
- make.top.left.bottom.and.right.equalTo(verticalScrollView);
- make.width.equalTo(verticalScrollView);#//垂直滚动宽度固定,这个很重要
- }];
- //过渡视图添加子视图
- UIView *lastView =nil;
- for (NSInteger index =0; index <10; index++) {
- UILabel *label = [[UILabelalloc]init];
- label.textAlignment =NSTextAlignmentCenter;
- label.backgroundColor = [UIColorcolorWithHue:(arc4random() %256 / 256.0)
- saturation:(arc4random() %128 /256.0) +0.5
- brightness:(arc4random() %128 /256.0) +0.5
- alpha:1];
- label.text = [NSStringstringWithFormat:@"第 %ld个视图", index];
-
-
- //添加到过渡视图,并设置子视图的约束
- [verticalContainerView addSubview:label];
- [label mas_makeConstraints:^(MASConstraintMaker *make) {
- make.left.and.right.equalTo(verticalContainerView);
- make.height.mas_equalTo(verticalScrollView.mas_height);
-
- if (lastView) {
- make.top.mas_equalTo(lastView.mas_bottom);
- }
- else {
- make.top.mas_equalTo(0);
- }
- }];
-
- lastView = label;
- }
-
- #// 设置过渡视图的底边距(此设置将影响到scrollView的contentSize)这个也是关键的一步
- [verticalContainerView mas_makeConstraints:^(MASConstraintMaker *make) {
- make.bottom.equalTo(lastView.mas_bottom);
- }];
