之前没接触过Android maui 开发,这几天刚摸索,有些不合理的地方欢迎指出。
首先添加微信sdk的绑定库
nuget 包:Chi.MauiBinding.Android.WeChat
项目地址:https://github.com/realZhangChi/MauiBinding
在项目目录 Platforms---Android 下建立文件夹wxapi,在wxapi文件夹下添加WXEntryActivity.cs,用来接收微信sdk的回调信息(Android接入指南 | 微信开放文档 (qq.com)),建好后修改代码为:

- namespace MauiApp7.Platforms.Android.wxapi
- {
- //将下面的中文"包名"替换成你实际的包名
- [Activity(Name = "包名.WXEntryActivity", Exported = true, TaskAffinity = "包名", LaunchMode = LaunchMode.SingleTask, Label = "微信回调")]
- //特别注意WXEntryActivity 是集成的Activity 不是MauiAppCompatActivity
- public class WXEntryActivity : Activity, IWXAPIEventHandler
- {
- private const string APP_ID = "xxxx";//更改为你自己在微信开放平台应用的appId
- private IWXAPI api;
-
- protected override void OnCreate(Bundle savedInstanceState)
- {
-
- base.OnCreate(savedInstanceState);
- api = WXAPIFactory.CreateWXAPI(this, APP_ID, false);
- try
- {
- Intent intent = this.Intent;
- api.HandleIntent(intent, this);
- }
- catch (Exception e)
- {
- Console.WriteLine("==========执行了OnCreate Exception:" + e.Message);
- }
- }
- public new void Dispose()
- {
-
- this.Dispose();
- }
- protected override void OnNewIntent(Intent intent)
- {
-
- base.OnNewIntent(intent);
- this.Intent = intent;
- api.HandleIntent(intent, this);
- }
- public void OnReq(BaseReq p0)
- {
-
- Finish();
- }
- public void OnResp(BaseResp p0)
- {
- //这里接收微信发来的消息
- if (p0.Type == 1)
- {
- if (p0.ErrCode_ == 0)
- {
- SendAuth.Resp authResp = (SendAuth.Resp)p0;
-
- }
- else
- {
- SendAuth.Resp authResp = (SendAuth.Resp)p0;
-
- }
- }
- Finish();
-
- }
- }
- }
注意:这个WXEntryActivity.cs 中的代码调试时进不去断点,而不是不执行(执行调试时没进断点一直认为不执行里面的方法,后面加了日志打印发现能打印出日志,实际是执行了的),需要手动添加日志打印。这个文件我只是随便加了几个回调信息,它可以接收所有微信的回调,具体的你自己修改。
另外这里接收到微信回调信息后如何通知静态html 我没找到好的解决方法使用了个绕弯路的方法,就是在调需要回调信息的方法时(例如微信登录,支付等),先链接服务器端的websocket,链接后在调用方法,接收到微信回调信息时向远程服务器发送个请求,远程服务器接收到请求通过websocket通知html。如果各位有更好的方法麻烦通知下我谢谢。
在根目录创建一个静态类PublicMethods.cs (类名位置都可以自定义,这个静态类主要给html js 调用使用的,js调用服务端方法 从 ASP.NET Core Blazor 中的 JavaScript 函数调用 .NET 方法 | Microsoft Learn)
注意其中的 #if ANDROID IOS 指在不同的平台下执行操作
- using Microsoft.JSInterop;
- using System;
- using System.Collections.Generic;
- using System.Diagnostics;
- using System.Linq;
- using System.Text;
- using System.Text.Json;
- using System.Threading.Tasks;
- using static System.Runtime.InteropServices.JavaScript.JSType;
- #if ANDROID
- using Android.Content;
- using Android.Views;
- using Android.Runtime;
- using Android.Net;
- using Com.Tencent.MM.Opensdk.Modelmsg;
- using Com.Tencent.MM.Opensdk.Openapi;
- using System.Runtime.InteropServices.JavaScript;
- using Org.Json;
- #elif IOS
- using UIKit;
- #endif
- namespace MauiApp7
- {
-
- public static class PublicMethods
- {
//微信登录 - [JSInvokable]
- public static Task WxLogin()
- {
- #if ANDROID
- IWXAPI api = WXAPIFactory.CreateWXAPI(Android.App.Application.Context, "wx00962a9afb38e1e9", true);
- var isReg = api.RegisterApp("wx00962a9afb38e1e9");
- if (isReg)
- {
- SendAuth.Req req = new SendAuth.Req();
- req.Scope = "snsapi_userinfo"; // 只能填 snsapi_userinfo
- req.State = "wechat_sdk_demo_test";
- api.SendReq(req);
- }
- Console.WriteLine("微信登录方法");
-
- #endif
- return Task.FromResult(0);
- }
//微信分享 - [JSInvokable]
- public static Task WxShare()
- {
- #if ANDROID
- IWXAPI api = WXAPIFactory.CreateWXAPI(Android.App.Application.Context, "wx00962a9afb38e1e9", true);
- var isReg = api.RegisterApp("wx00962a9afb38e1e9");
- if (isReg)
- {
- string text="test";
- //初始化一个 WXTextObject 对象,填写分享的文本内容
- WXTextObject textObj = new WXTextObject();
- textObj.Text = text;
- //用 WXTextObject 对象初始化一个 WXMediaMessage 对象
- WXMediaMessage msg = new WXMediaMessage();
- msg.MediaObject_ = textObj;
- msg.Description = text;
- SendMessageToWX.Req req = new SendMessageToWX.Req();
- req.Transaction = Guid.NewGuid().ToString("N");
- req.Message = msg;
- req.Scene = SendMessageToWX.Req.WXSceneSession;
- //调用api接口,发送数据到微信
- api.SendReq(req);
- }
- Console.WriteLine("微信分享方法");
-
- #endif
- return Task.FromResult(0);
- }
- }
- }
至此服务端代码完毕,下面时html代码
1.新建maui Blazor应用,修改MainPage.xaml 中的代码,删除BlazorWebView 下子内容,修改后的代码为
- <BlazorWebView x:Name="blazorWebView" HostPage="wwwroot/index.html" BlazorWebViewInitialized="blazorWebView_BlazorWebViewInitialized">
-
- </BlazorWebView>
修改MainPage.xaml.cs中代码添加BlazorWebViewInitialized 事件,此事件是允许BlazorWebView在Android平台下能够同时访问http和https的混合请求,需搭配android:usesCleartextTraffic="true" 使用 具体参考 maui BlazorWebView Android 中混合使用https和http - 落叶子 - 博客园 (cnblogs.com)
- private void blazorWebView_BlazorWebViewInitialized(object sender, Microsoft.AspNetCore.Components.WebView.BlazorWebViewInitializedEventArgs e)
- {
-
- #if ANDROID
- e.WebView.Settings.MixedContentMode = Android.Webkit.MixedContentHandling.AlwaysAllow;
- #endif
- }
2.将静态html或者打包好的vue、uniapp项目拷贝到wwwroot目录下(先删除此目录下项目生成的文件),因为我测试是用的uniapp打包的html,因此下面都是基于uniapp的方式实现的,其他的都一样的步骤
将uniapp打包后的项目拷贝后修改index.html文件,添加_framework/blazor.webview.js,就是在index.html中的js 文件上面添加blazor.webview.js的引用
- <script src="_framework/blazor.webview.js" autostart="false" crossorigin="anonymous"></script>
- <script src=./static/js/chunk-vendors.22eccfa8.js></script>
- <script src=./static/js/index.5efaff53.js></script>
3.在需要执行微信skd的方法时直接通过js方法调用(微信sdk方法需先在PublicMethods.cs 静态类中注册) 从 ASP.NET Core Blazor 中的 JavaScript 函数调用 .NET 方法 | Microsoft Learn
- DotNet.invokeMethodAsync('MauiApp7', 'WxLogin')
- .then(data => {
- console.log(data);
- });
这样就可以成功调用微信sdk的方法了
